The new Air8 charger from iSDT is the successor of the Q8 and offers 500W charging power at a weight of only 169 grams and almost tiny dimensions of 80x80x34 mm. It can charge 1-8s LiPo or LiHv batteries with max. 20A. The new scOS 2.0 offers improved system stability and new functions such as Dark Mode, DC Power Mode and a mode to bring defective batteries to 0V.
The Air 8 supports the Batt Air function, the necessary Batt Air plugs are available separately!
The IPS display ensures very good readability even in sunlight.
Technical data:
- Input voltage: 10-34V – DC voltage
- Input current max: 20A
- Output voltage: 1-34V
- charging power: 500W (from 27V input voltage)
- discharge power: 15W
- charging current: 0.1-20A
- Discharge current: 0.1-1.5A
- Balancing current: 1500mA/cell
- Adjustable end-of-charge voltage: up to 4.35V for LiHV
- number of cells – battery type: 1-8 LiXX, 1-8 LiHV & ULiHv 1-16 NiXX, 1-12 Pb
- Weight: 169 g
- Dimensions: 80x80x34mm
- colour display: 2.4″ IPS LCD, easy to read even in daylight and at an angle of view of up to 178
- updateable via USB
- multilingual menu navigation, German can be selected
